Characteristics

1. Variable frequency speed regulation;

2. Small deceleration and large output torque;

3. High measurement precision;

6. Constant temperature control;

8. Two potentiometers respectively located at two sides of the bench, which is used for controlling speed without interfering;

9. Speed, count, temperature, air pressure, advance angle are displayed on 15-inch LCD;

10. Built-in air resource.

Function

1. Measuring each cylinder’s injected oil quantity at various rotation speeds;

2. Checking each cylinder’s injection time statically;

4. Checking the electromagnetic valve of distribution pumps;

5. Checking the pneumatic speed governor’s performance;

6. Checking the pressure compensator’s performance;

7. Measuring the returned oil quantity of distribution pumps;

8. Measuring the internal pressure of the distribution pump body;

9. Checking the pneumatic speed governor’ s vacuum performance;

10. Measuring rack travel;

11. Checking the sealing of fuel injection pump body.

Technical Parameters

1. Adjustable rotation speed range: 0～4000RPM

2. Double series of graduates: 45cc and 1500cc (optional)

3. Volume of oil tank: 60L

4. Temperature stabilization: 40±2℃

5. Test oil filtering unit: 5μ

6. DC supply: 12V/24V

7. Fuel feed pressure: low: 0～0.4MPa, high: 0～4Mpa

8. Air pressure: 0～0.3MPa,

9. 3-phase power supply: 380V/50Hz or according to requirements

10. Flywheel inertia’s moment: 0.8KG·M²

11. Center height:125MM

12. Output power: 7.5KW, 11KW, 15KW or according to requirements

13. Overall dimensions(MM): 2360×960×1870 or according to requirements
